Specification

• Part #: 8499
• Product Name: POE Analog-to-IP Encoder
• Analog Video Input: 1 Channel
• Network Video Output: 1 Channel
• Video Compression Standard: H.264/H.265
• Video Encoding Resolution: 720P/1080P
•

• Supported Protocols: TCP/IP, HTTP, RTSP, ONVIF, RTMP, DHCP
• Default IP Address: 192.168.1.10 (Cannot access by IE, but need special software)
• Default Username/Password: Username: admin, Password: admin
• ONVIF Port: 8388
• RTSP Main Stream: Rtsp://localhost/0
• RTSP Secondary Stream: Rtsp://localhost/1
•

• Baud Rate: 9600
• Protocol: PELCO-D
• Address Code: 000
• Power Supply: PoE, with IEEE 802.af standard
• Power Consumption: 1W
• Weight: 0.1KG
•

• Download PDF Specification: Click Here
